Water Garden Hose DIY Grade

  • Home
  • Water Garden Hose DIY Grade

Technical Specifications

Tube

Oil Mist Resistance Rubber

Cover

High Strength Rubber, Several Finishes available

Reinforcement

Single or Multiple Layers of High Strength Polyester Yarn

Fittings

Anodized Alumium/ Brass End Fittings With Anodized Alumium/Bass Ferrules

Pressure

100:300PSI, 150:500 PSI* (Max. Working Pressure: Min. Burst Pressure)

Oil Resistance

Exceeds RMA Class ‘C’ Oil Resistance

Accessories

Bend- Restrictor Sleeve to prevent damage near ends

Advantages

Economical General Purpose Water / Garden Hose, Good Mechanical Properties, High burst Strength, Handles Hot Water upto 160°F

technical-air-hose

PREMIER WATER/ GARDEN HOSE DIY GRADE WITH FITTING
PART NO. I.D. W.P. LENGTH FITTING SAFETY RATIO
W.P. : B.P.		 COILS/ CARTON
PSI BAR
PRDWGH580025 5 /8” 500 35 25’ 3 /4” N.H. 3:01 4
PRDWGH580050 5 /8” 500 35 50’ 3 /4” N.H. 3:01 4
PRDWGH580100 5 /8” 500 35 100’ 3 /4” N.H. 3:01 2
PRDWGH340025 3 /4” 500 35 25’ 3 /4” N.H. 3:01 4
PRDWGH340050 3 /4” 500 35 50’ 3 /4” N.H. 3:01 3
PRDWGH340100 3 /4” 500 35 100’ 3 /4” N.H. 3:01 1


PART NO. I.D. W.P. LENGTH FITTING SAFETY RATIO
W.P. : B.P.		 COILS/ CARTON
PSI BAR
PRDWGH120025 1 /2” 300 20 25’ 3 /4” N.H. 3:01 4
PRDWGH120050 1 /2” 300 20 50’ 3 /4” N.H. 3:01 4
PRDWGH120100 1 /2” 300 20 100’ 3 /4” N.H. 3:01 2
PRDWGH580025 5/8” 300 20 25’ 3 /4” N.H. 3:01 4
PRDWGH580050 5 /8” 300 20 50’ 3 /4” N.H. 3:01 4
PRDWGH580100 5 /8” 300 20 100’ 3 /4” N.H. 3:01 2
PRDWGH340025 3 /4” 300 20 25’ 3 /4” N.H. 3:01 4
PRDWGH340050 3 /4” 300 20 50’ 3 /4” N.H. 3:01 3
PRDWGH340100 3 /4” 300 20 100’ 3 /4” N.H. 3:01 1

PREMIER WATER/GARDEN HOSE DIY GRADE CUSTOM LENGTH
PART NO. I.D. WORKING PRESSURE
INCH MM BAR MPa PSI
PRDWGH12125 1/4 12.5 10.2 1 145
PRDWGH58016 5/8 16 10.2 1 145
PRDWGH34019 3/4 19 10.2 1 145
PRDWGH10025 1 25 10.2 1 145
PRDWGH12125 1/2 12.5 7 0.7 100
PRDWGH58016 5/8 16 7 0.7 100
PRDWGH34019 3/4 19 7 0.7 100
PRDWGH10025 1 25 7 0.7 100
